- 05. Spindle 5 steps
In Progress
This guide is currently being written. Reload periodically to see the latest changes.
Private
This guide will not appear in search results and can only be viewed by team members!
Quiz
0
-
-
Insert wisdom here
-
-
-
Rat Rig 80mm Spindle Mount
-
4x M6x70 Cap Head Screw
-
4x M6 Square nut
-
4x M8x30 Low Profile Cap Head Screw
-
2x M8x12 Low Profile Cap Head Screw
-
12x M8x22 Cap Head Screw
-
-
-
Rat Rig Spindle Mount - 80mm
-
M8x30 Low Profile Cap Head Screw
-
M8x12 Low Profile Cap Head Screw
-
Insert the screws through each hole in the spindle mount and secure it into the spindle mount body
-
-
-
Assembly from the previous step
-
M6x70 Cap Head Screws
-
Square nut M6
-
Do not fully fasten the M6x70 screws at this point. They will be used to hold the spindle in place later in the assembly
-
-
-
Spindle mount assembly
-
M8x22 Cap Head Screws
-
Place the screws in the designated holes, they will be tightened on the next step.
-
